Cable Tie
NORMAFIX® Cable Tie PA 6.6 - Specs
Cable tie for securing cables in electrical installations, industrial wiring, automotive
Made of polyamide 6.6
Resistant to extreme temperatures and numerous external agents. Quick and safe assembly.
The black cable tie offers excellent resistance to UV rays thanks to added "carbon black".
Material with a low coefficient of friction and enlarged end
Faster installation
Made of Polyamide 6.6
Optimum resistance to
extreme temperatures, bases,
oils, greases ...
Rounded and smooth edges
Easy and safe assembly
"Carbon Black" added in Black cable tie flange
Increased resistance to UV rays
Suitable for outdoor use
Variety of colors
Available in: black, white,
red, yellow, green, blue.
01
Cable Tie
NORMAFIX® Cable Tie PA 6.6 - Bulk packaging
Bags of 100 units packed in bulk carton boxes also identified with their reference number and the cable tie
colour for better warehouse organisation.
Measures mm
Reference
Bundle
Tensile
Width x
Bag
Carton
max (mm)
strength
White
Black
Long
2,5 x 98
21 mm.
8 Kgs.
860 0130 201
860 0230 201
100
35.000
2,6 x 160
40 mm.
8 Kgs.
860 0130 302
860 0230 302
100
25.000
2,6 x 200
52 mm.
8 Kgs.
860 0130 303
860 0230 303
100
20.000
3,6 x 140
35 mm.
13 Kgs.
860 0130 401
860 0230 401
100
20.000
3,6 x 200
50 mm.
13 Kgs.
860 0130 402
860 0230 402
100
15.000
3,6 x 290
80 mm.
13 Kgs.
860 0130 403
860 0230 403
100
10.000
3,6 x 370
103 mm.
13 Kgs.
860 0130 404
860 0230 404
100
7.500
4,5 x 120
24 mm.
20 Kgs.
860 0130 501
860 0230 501
100
15.000
4,5 x 160
40 mm.
20 Kgs.
860 0130 502
860 0230 502
100
12.000
4,8 x 178
45 mm.
22 Kgs.
860 0130 601
860 0230 601
100
12.000
4,8 x 200
50 mm.
22 Kgs.
860 0130 602
860 0230 602
100
10.000
4,8 x 250
68 mm.
22 Kgs.
860 0130 603
860 0230 603
100
9.000
4,8 x 290
79 mm.
22 Kgs.
860 0130 604
860 0230 604
100
7.500
4,8 x 360
103 mm.
22 Kgs.
860 0130 605
860 0230 605
100
6.000
4,8 x 390
106 mm.
22 Kgs.
860 0130 606
860 0230 606
100
5.000
4,8 x 430
115 mm.
22 Kgs.
860 0130 607
860 0230 607
100
5.000
7,8 x 180
45 mm.
55 Kgs.
860 0130 702
860 0230 702
100
5.000
7,8 x 240
63 mm.
55 Kgs.
860 0130 703
860 0230 703
100
4.000
7,8 x 300
80 mm.
55 Kgs.
860 0130 704
860 0230 704
100
3.500
7,8 x 365
100 mm.
55 Kgs.
860 0130 705
860 0230 705
100
2.500
7,8 x 450
130 mm.
55 Kgs.
860 0130 706
860 0230 706
100
2.500
7,8 x 540
158 mm.
55 Kgs.
860 0130 707
860 0230 707
100
2.000
7,8 x 750
200 mm.
55 Kgs.
860 0130 708
860 0230 708
100
1.200
9 x 780
233 mm.
77 Kgs.
860 0130 801
860 0230 801
100
1.000
12,6 x 500
143 mm.
110 Kgs.
860 0130 902
860 0230 902
50
1.000
12,6 x 1000
302 mm.
110 Kgs.
860 0130 905
860 0230 905
50
500
Clable tie Hand Tools
For cable tie PA 6.6
For cable tie PA 6.6 y PA 12
Reference: 860 1000 001
Reference: 860 1000 004
Reference: 860 1000 005
Reference: 860 1000 006
From 2,2 to 4,8mm.
From 4,8 to 7,8mm
From 3,6 to 13mm.
From 3,6 to 9 mm.
80
Cable Tie
NORMAFIX® CT Bylon plug support flange PA 6.6
It allows the installation of the cable tie into the wall.
Reference
Denomination
Bag
White
Black
Gray
without fins
base 8 mm
860 0701 002
860 0701 001
-
100
base 6 mm
860 0701 112
860 0701 111
860 0703 111
100
with fins
base 8 mm
860 0701 102
860 0701 101
860 0703 101
100
NORMAFIX® CABLE TIE SUPPORT WITHOUT STICK
Quick and easy installation. It allows the cable tie installation into the wall
2 Entries
Reference
Cable tie
Dimensions (mm.)
width
Bag
White
Black
mm.
A
B
C
F
H
860 0911 001
860 0912 001
3,6
19
19
4,1
4
5
100
860 0911 002
860 0912 002
4,8
27
27
4,8
6
6,5
100
NORMAFIX® CABLE TIE SUPPORT WITH STICK
Immediate positioning. Resistant to high temperatures and UV. Applicable on all surfaces.
2 Entries
Reference
Cable tie
Dimensions (mm.)
width
Bag
White
Black
mm.
A
B
C
F
H
860 0931 001
860 0932 001
3,6
19
19
4,1
4
5
100
860 0931 002
860 0932 002
4,8
27
27
4,8
6
6,5
100
